Do your power supplies stop due to unexpected external disturbances?
You can increase your equipment operating rates by selecting Power Supplies that have a high resistance to external disturbances.
Place of Origin: | JAPAN |
Brand Name: | OMRON |
Model Number: | S8FS-C15024J |
Delivery Time: | 0-3 days |
---|---|
Payment Terms: | T/T, PayPal, Western Union |
Supply Ability: | 1000 pcs/day |
Available: | NEW in box |
Lead Time: | 0-3 Days |
Payment Terms: | T/T, Western Union |
Description: | Omron Power Supply 150W 24V 6.5A |
---|
Do your power supplies stop due to unexpected external disturbances?
You can increase your equipment operating rates by selecting Power Supplies that have a high resistance to external disturbances.
In locations where the supply of power is not stable, it is common for abnormal voltages around 300 VAC to be input momentarily. The S8FS withstands this type of momentary abnormal input voltage.
*1. It is not a guaranteed value.
Malfunctions in power supplies can be caused by strong noise of several tens of kHz transmitted from inverters or motors on the same AC line. OMRON measured the noise frequencies and sizes that occurred in actual machines in the past and used them as a standard to improve the noise resistance of the S8FS by harnessing circuit design knowhow to prevent noise from reaching the control section
The catalog value conforms to the value specified in IEC 61000-4-5, but it has been confirmed that the ability has a margin of 1.5 times that value.
*1. It is not a guaranteed value.
Power rating | 150 W | |||||||
---|---|---|---|---|---|---|---|---|
Output voltage (VDC) | 5 V | 12 V | 15 V | 24 V | 36 V | 48 V | ||
Efficiency * | 115 VAC input | 81% typ. | 84% typ. | 85% typ. | 86% typ. | 86% typ. | 87% typ. | |
230 VAC input | 82% typ. | 85% typ. | 86% typ. | 87% typ. | 87% typ. | 88% typ. | ||
Input | Voltage range * | Single phase 90 to 132 VAC , Single phase 180 to 264 VAC , 254 to 373 VDC Select with the switch. (The L terminal for the DC input is the positive side and safety standards do not apply.) (Derating is required according to the input voltage. Refer to Derating Curves on Data Sheet.) |
||||||
Frequency * | 50 /60 Hz (47 to 450 Hz) | |||||||
Current * | 115 VAC input | 2.8 A typ. | ||||||
230 VAC input | 1.6 A typ. | |||||||
Power factor | -- | |||||||
Leakage current |
115 VAC input | 0.50 mA | 0.50 mA | 0.50 mA | 0.50 mA | 0.40 mA | 0.50 mA | |
230 VAC input | 0.75 mA | 0.75 mA | 0.75 mA | 0.70 mA | 0.60 mA | 0.70 mA | ||
Inrush current * (for a cold start at 25°) |
115 VAC input | 32 A typ. | ||||||
230 VAC input | 32 A typ. | |||||||
Output | Rated Output Current | 26 A | 12.5 A | 10 A | 6.5 A | 4.3 A | 3.3 A | |
Voltage adjustment range * | -10% to 10% (with V. ADJ) | |||||||
Ripple & Noise voltage * |
100 to 120 VAC/200 to 240 VAC input |
50 mVp-p max. |
90 mVp-p max. |
110 mVp-p max. |
100 mVp-p max. |
200 mVp-p max. |
120 mVp-p max. |
|
Input variation influence * | 0.5% max. | |||||||
Load variation influence * | 1.0% max. | |||||||
Temperature variation influence |
100 to 120 VAC/200 to 240 VAC input |
0.03%/°C max. | ||||||
Startup time * |
115 VAC input | 770 ms typ. | 730 ms typ. | 740 ms typ. | 770 ms typ. | 730 ms typ. | 760 ms typ. | |
230 VAC input | 750 ms typ. | 720 ms typ. | 730 ms typ. | 760 ms typ. | 720 ms typ. | 750 ms typ. | ||
Hold time * | 115 VAC input | 29 ms typ. | 24 ms typ. | 27 ms typ. | 23 ms typ. | 23 ms typ. | 21 ms typ. | |
230 VAC input | 35 ms typ. | 30 ms typ. | 31 ms typ. | 28 ms typ. | 29 ms typ. | 27 ms typ. | ||
Addi- tional func- tions |
Overload protection | Yes, automatic reset | ||||||
Overvoltage protection * | Yes, 115% or higher of rated output voltage, power shut off (shut off the input voltage and turn on the input again) |
|||||||
Overheat protection | No | |||||||
Series operation | Yes (For up to 2 Power Supplies, external diodes are required.) | |||||||
Parallel operation | No (However, backup operation is possible, external diodes are required.) | |||||||
Remote sensing | No | |||||||
Remote control | No | |||||||
Output indicator | Yes (LED: Green) | |||||||
Insula- tion |
Withstand voltage | 3 kVAC for 1 min. (between all input terminals and output terminals) current cutoff 20 mA |
||||||
2 kVAC for 1 min. (between all input terminals and PE terminals) current cutoff 20 mA |
||||||||
1 kVAC for 1 min. (between all output terminals and PE terminals) current cutoff 20 mA |
||||||||
Insulation resistance | 100 MΩ min. (between all output terminals and all input terminals/PE terminals) at 500 VDC |
|||||||
Envi- ron- ment |
Ambient operating temperature | -20 to 60°C (Derating is required according to the temperature. Refer to Derating Curves on Data Sheet.) (with no condensation or icing) |
||||||
Storage temperature | -40 to 85°C (with no condensation or icing) | |||||||
Ambient operating humidity | 20% to 90% (Storage humidity: 10% to 95%) | |||||||
Vibration resistance | 10 to 55 Hz, 0.375-mm half amplitude for 2 h each in X, Y, and Z directions 10 to 500 Hz, 0.26-mm half amplitude for 1 h each in X, Y, and Z directions |
|||||||
Shock resistance | 150 m/s2, 3 times each in ±X, ±Y, ±Z directions | |||||||
Relia- bility |
MTBF | 135,000 hrs min. | ||||||
Life expectancy * | 10 years min. | |||||||
Con- struc- tion |
Dimensions (W × H × D) | Refer to Dimensions. | ||||||
Weight | 500 g max. | |||||||
Cooling fan | No | |||||||
Degree of protection | -- | |||||||
Stan- dards |
Harmonic current emissions | Conforms to EN 61000-3-2, GB17625.1 | ||||||
EMI | Conducted Emissions |
Conforms to EN 61204-3 Class B, EN 55011 Class B, GB9254 | ||||||
Radiated Emissions |
Conforms to EN 61204-3 Class B, EN 55011 Class B, GB9254 | |||||||
EMS | Conforms to EN 61204-3 high severity levels | |||||||
Safety Standards | Approved Standards UL: cURus UL 62368-1 (Recognition) OVC II Pol2 CSA: cURus C22.2 No62368-1 CCC: GB4943 Conformed Standards EN: EN 62368-1 OVC II Pol2 EAC (TR CU 004 / 2011, TR CU 020 / 2011) RCM (EN61000-6-4) |
|||||||
Marine Standards | No | |||||||
SEMI | No |
We could SUPPLY:
Relation Items:
Power rating |
Input voltage | Output voltage (VDC) |
Output current |
Built- in fan |
Model with terminal block facing upward |
Model with terminal block facing forward |
Model wtih DIN rail |
---|---|---|---|---|---|---|---|
15 W | 100 to 240 VAC (allowable range: 85 to 264 VAC or 120 to 370 VDC *1) |
5 V | 3 A | None | -- | S8FS-C01505J | S8FS-C01505D |
12 V | 1.3 A | S8FS-C01512J | S8FS-C01512D | ||||
15 V | 1 A | S8FS-C01515J | S8FS-C01515D | ||||
24 V | 0.7 A | S8FS-C01524J | S8FS-C01524D | ||||
25 W | 5 V | 5 A | S8FS-C02505 | S8FS-C02505J | S8FS-C02505D | ||
12 V | 2.1 A | S8FS-C02512 | S8FS-C02512J | S8FS-C02512D | |||
15 V | 1.7 A | S8FS-C02515 | S8FS-C02515J | S8FS-C02515D | |||
24 V | 1.1 A | S8FS-C02524 | S8FS-C02524J | S8FS-C02524D | |||
35 W | 5 V | 7 A | S8FS-C03505 | S8FS-C03505J | S8FS-C03505D | ||
12 V | 3 A | S8FS-C03512 | S8FS-C03512J | S8FS-C03512D | |||
15 V | 2.4 A | S8FS-C03515 | S8FS-C03515J | S8FS-C03515D | |||
24 V | 1.5 A | S8FS-C03524 | S8FS-C03524J | S8FS-C03524D | |||
50 W | 5 V | 10 A | S8FS-C05005 | S8FS-C05005J | S8FS-C05005D | ||
12 V | 4.2 A | S8FS-C05012 | S8FS-C05012J | S8FS-C05012D | |||
15 V | 3.4 A | S8FS-C05015 | S8FS-C05015J | S8FS-C05015D | |||
24 V | 2.2 A | S8FS-C05024 | S8FS-C05024J | S8FS-C05024D | |||
48 V | 1.1 A | S8FS-C05048 | S8FS-C05048J | S8FS-C05048D | |||
75 W | 5 V | 14 A | S8FS-C07505 | S8FS-C07505J | S8FS-C07505D | ||
12 V | 6.2 A | S8FS-C07512 | S8FS-C07512J | S8FS-C07512D | |||
15 V | 5 A | S8FS-C07515 | S8FS-C07515J | S8FS-C07515D | |||
24 V | 3.2 A | S8FS-C07524 | S8FS-C07524J | S8FS-C07524D | |||
48 V | 1.6 A | S8FS-C07548 | S8FS-C07548J | S8FS-C07548D | |||
100 W | 100 to 120 VAC, 200 to 240 VAC (allowable range: 85 to 132 VAC, 176 to 264 VAC, or 248 to 373 VDC (Select with the switch.) *2) |
5 V | 20 A | S8FS-C10005 | S8FS-C10005J | S8FS-C10005D | |
12 V | 8.5 A | S8FS-C10012 | S8FS-C10012J | S8FS-C10012D | |||
15 V | 7 A | S8FS-C10015 | S8FS-C10015J | S8FS-C10015D | |||
24 V | 4.5 A | S8FS-C10024 | S8FS-C10024J | S8FS-C10024D | |||
36 V | 2.8 A | S8FS-C10036 | S8FS-C10036J | S8FS-C10036D | |||
48 V | 2.3 A | S8FS-C10048 | S8FS-C10048J | S8FS-C10048D | |||
150 W | 100 to 120 VAC, 200 to 240 VAC (allowable range: 90 to 132 VAC, 180 to 264 VAC, or 254 to 373 VDC (Select with the switch.) *2) |
5 V | 26 A | S8FS-C15005 | S8FS-C15005J | S8FS-C15005D | |
12 V | 12.5 A | S8FS-C15012 | S8FS-C15012J | S8FS-C15012D | |||
15 V | 10 A | S8FS-C15015 | S8FS-C15015J | S8FS-C15015D | |||
24 V | 6.5 A | S8FS-C15024 | S8FS-C15024J | S8FS-C15024D | |||
36 V | 4.3 A | S8FS-C15036 | S8FS-C15036J | S8FS-C15036D | |||
48 V | 3.3 A | S8FS-C15048 | S8FS-C15048J | S8FS-C15048D | |||
200 W | 5 V | 40 A | S8FS-C20005 | S8FS-C20005J | S8FS-C20005D | ||
12 V | 17 A | S8FS-C20012 | S8FS-C20012J | S8FS-C20012D | |||
24 V | 8.8 A | S8FS-C20024 | S8FS-C20024J | S8FS-C20024D | |||
36 V | 5.9 A | S8FS-C20036 | S8FS-C20036J | S8FS-C20036D | |||
48 V | 4.43 A | S8FS-C20048 | S8FS-C20048J | S8FS-C20048D | |||
350 W | 5 V | 60 A | Yes | S8FS-C35005 | S8FS-C35005J | S8FS-C35005D | |
12 V | 29 A | S8FS-C35012 | S8FS-C35012J | S8FS-C35012D | |||
24 V | 14.6 A | S8FS-C35024 | S8FS-C35024J | S8FS-C35024D | |||
36 V | 9.7 A | S8FS-C35036 | S8FS-C35036J | S8FS-C35036D | |||
48 V | 7.32 A | S8FS-C35048 | S8FS-C35048J | S8FS-C35048D |
Note: You can use brackets that are sold separately to mount the Power Supplies to DIN Rail. Refer to Mounting Brackets
(Order Separately) on Data Sheet.
*1. The range for compliance with EC Directives and safety standards (UL, EN, etc.) is 100 to 240 VAC.
*2. The range for compliance with EC Directives and safety standards (UL, EN, etc.) is 100 to 120 VAC, 200 to 240 VAC.
